Performance Records
Record Storage
Records are located as follow:
• The 15-minute records are saved in RAM on the NCU. During a controlled shut down
of the NE (via your management system), the records are stored on the compact
flash (CF) on the NCU. Upon start up of the NE, the 15-minute records stored on the
CF are restored to the RAM. If the NE is powered off, or the NCU is extracted, these
records cannot be stored on the compact flash. The records are lost in this situation,
and a gap in the History 15-minute record will be seen.
• The 24-hour records are stored in the CF on the NCU.
• The 1-week records are stored on the CF on the NCU.
This means that if there is an uncontrolled shutdown, for example, if you re-seat the
NCU, the 15-minute records are lost. The 24-hour and 1-week records, however, are
maintained.
Saving Performance Monitoring History Records
This procedure describes how to export performance monitoring history records.
Step 1 Select .
Step 2 In the Navigation Tree, select
Shelf
>
Module slot
.
Step 3 Select the blade corresponding to the port or data channel for which you wish
to export the history records (for example, the Network Ports blade).
Step 4 Click the History tab.
Step 5 Select 15 Minutes, Daily, or Weekly history records.
The Main Pane displays the history record for the interval you selected.
Step 6 Click Export, then follow the Windows dialog to save the records.
Step 7 Repeat this procedure for each interval, port, and module for which you wish to
save history records.
652 FSP 3000R7 Maintenance and Troubleshooting Manual - Product Release 16.2 - Document Issue A
