Troubleshooting Control Plane Issues
+------------------- PTP & Physical Connections Table --------------------+
| |
| Shelf Slot Equipment Class |
| [All] [All ] [All ] [All ] |
| |
| From AID Eqpt To AID Eqpt Conn Class |
| +----------------------------------------------------------+ |
| |PTP-1 OL PTP-2-N EROADM 2WAY STD | |
| |PTP-2 OL PTP-1-3-C1 10TCC10G 1WAY NON-STD | |
| |PTP-1-3-C1 10TCC10G -- -- -- -- | |
| |PTP-1-3-C2 10TCC10G PTP-4-8-NE 4TCA4G 2WAY STD | |
| |PTP-1-3-N 10TCC10G PTP-2-C1 EROADM 2WAY STD | |
| |PTP-1-5-C WCA10G-C PTP-4-5-C1 5TCE10GT 2WAY STD | |
| |PTP-1-5-N WCA10G-C -- -- -- -- | |
| |PTP-1-6-N 5TCE10GT PTP-6-11-N2 4OPCM 1WAY STD | |
| |PTP-1-7-C1 OSCMPN -- -- -- -- | |
| |PTP-1-7-C2 OSCMPN PTP-1-A-C2 NCU-II 2WAY STD | |
| |PTP-1-7-C3 OSCMPN -- -- -- -- | |
| +----------------------------------------------------------+ |
| Click on From AID to view, edit, create or delete Physical Connections |
| |
| [ Cancel ] [ Top ] [ Bottom ] [ Page Up ] [Page Down] [ Refresh ] |
| |
--------------------------------------------------------------------------
Step 2 Verify the current physical connections enable the TE link to properly
transverse through this node.
Step 3 Repeat Step 1 to Step 2 for each node the TElink transverses through.
Checking OSPFSettings
To use the pathways computed by the control plane, OSPF settings at each NE must be
entered correctly when the node is provisioned. This section addresses the following
procedures to troubleshoot some commonly occurring connectivity problems:
“Verifying All Nodes are Listed” on p.563
“Ensuring the Correct Topology” on p.564
“Verifying OSPFNeighbors” on p.565
Verifying All Nodes are Listed
Verify that all nodes of the OSPFdomain are listed in the Target Identifier (TID) IPtable,
as described in the following procedure.
Step 1 Select System Management > System IPSettings > TID IP Table.
The System IPSettingswindow displays the list of nodes in this
OSPFdomain.
