Troubleshooting Access Type WDM Channel Modules
LED-Status Potential Cause Solution for Troubleshooting
O/E Loop C/R C/T N/R N/T
blinking
Red/
Green
Off Off Off
(flashing
Red)
solid
Green
solid Green Regenerator Mode
and network laser are
activated.
1 Check the Regenerator settings.
2 Check the network laser setting.
If the condition continues once the module has lost and
regained power or all loops have been turned off, it should be
returned to ADVA Optical Networking for repair.
solid Red Off Off flashing
Red
solid
Yellow
solid Green Regenerator Mode is
activated, but the
network clock setting
does not match to the
transmitted data rate.
Check the Regenerator settings
If the condition continues once the module has lost and
regained power or all loops have been turned off, it should be
returned to ADVA Optical Networking for repair.
Table 48: LED Status of the WCA-PC-10G-V
WCA-PCN-2G5U
This subsection will help you resolve issues that can be experienced on WCA-PCN-2G5U modules.
It assumes that all measurements for the C/R, C/T, N/R East, N/R West, N/T West and N/T East interfaces are within ADVA Optical Networking specifications and that
you have verified that the application wavelength is the same as the wavelength for the FSP 3000R7 module’s client interface. If not, refer to “Finding Your Problem -
Follow the Light” on p.53.
CAUTION
Follow all the instructions precisely. If you do not supply the specified attenuation on given steps, you could destroy the module being tested. As soon as
the near-end and the far-end WCA-PCN-2G5U modules in a link are synchronized, the network link is up. The network interface LEDs light up solid green
or blink green depending on the configured transmission mode: Multiplexer NE Only, Multiplexer NW Only, Multiplexer NE & NW or Regenerator 1-Way.
286 FSP 3000R7 Maintenance and Troubleshooting Manual - Product Release 16.2 - Document Issue A
