Replacing an Optical Module
Do not leave the shelf slot empty left by the removed module! To fill the empty slot
only use an appropriate dummy module. An empty shelf slot will result in an
inhomogeneous air stream and contamination of the installed optical modules and
components with dust and debris inside the shelf.
Step 12 Insert the dummy module as described in “Inserting a Dummy Module” on
p.773.
Step 13 Repeat this procedure for each optical module to be removed from a shelf slot.
Step 14 If available, mount the front cover to the shelf as described in “Mounting an
SH7HU, SH9HU, or SHX9HU Front Cover” on p.769.
Step 15 Detach the wrist strap from your wrist, disconnect the grounding cable from the
ESD grounding point on the shelf (if available) or the rack and lay the grounding
cable aside.
Step 16 Store the optical cables for future use.
Where necessary, return the defective module to ADVA Optical Networking for
repair. For details on returning modules, refer to the Installation and
Commissioning Manual.
If you have any problems that result in a deviation from the removal procedure
described above, contact ADVA Optical Networking Technical Services.
Installing an Optical Module
This section describes the procedure for adding channel modules, optical filter modules,
optical amplifiers, and protection modules. The procedure is common to all optical module
types.
For specific information about each optical module, refer to the Hardware Description.
Note
Before connecting fiber-optic cables, install the optical module and
pluggable transceivers to the FSP 3000R7 system, as described in this
section. After physical installation, the module boots up.
Please wait about 1 minute until the boot, configuration, and initialization
time for protection is completed. Then fiber-optic cables can be
connected to the installed optical module and pluggable transceivers.
CAUTION
Only Service Personnel are allowed to perform this procedure.
Additional Information
All optical modules are designed as plug-in modules that are compatible with any FSP
3000R7 shelf. Adding an optical module does not affect the operation of currently
installed modules in the shelf. There are no fixed slot positions for specific optical
modules. Each optical module can be inserted into a shelf slot without the use of any
tools.
