Replacing an Optical Module
Replacing an Optical Module
This section describes how to remove and install optical modules.
The following subsections are covered:
“Removing an Optical Module” on p.656
“Installing an Optical Module” on p.660
Removing an Optical Module
This section describes the procedure of removing channel modules, optical filter
modules, optical amplifiers and protection modules. The procedure is common and
independent of the optical module types. The term “optical module“refers to all of the
modules mentioned above.
For specific information about each optical module, refer to the Hardware Description.
CAUTION
Only Service Personnel are allowed to perform this procedure.
Additional Information
Removal of NCU, SCU, OSC and channel modules does not affect the operation of the
other modules installed in the shelf. If removing an optical module permanently, the
corresponding database entity has to be deleted from the database.
Required Equipment
Before starting the procedure, ensure the following is available.
• Torx screwdriver TX10 to assist in loosening the knurled screws
• Appropriate dummy module to fill the empty slot
• ESD-preventive wrist strap or other personal grounding device
• Suitable grounded surface or an antistatic mat for placing the optical module
• Original shipping box including the static-protective package for saving the removed
module
• Appropriate blind plugs for inserting into the unused module receptacles
• Appropriate protective caps for covering the fiber connectors
• Tagging materials if necessary
Removal Procedure
Follow these steps to remove an optical module from a shelf slot.
To prevent ESD damage to the equipment take normal static precautions
for removing optical modules.
