Adva FSP 3000R7 - Example of Configuring the NCU

Configuring In-band Management
Example of Configuring the NCU
This procedure describes how to configure the NCU.
Step 1 Log on to the near-end node, then select .
Step 2 In the Navigation Tree, select Shef 1 > NCU slot .
Step 3 Select the Management Links to Module Management Channels blade.
Step 4 To create a PPPIP facility (for example LINK-1-A-4), click Add End Point.
In response, the Add facility window appears:
Step 5 Enter the following settings:
• Set OSPF Routing to Disable (unless your network requires OSPF
routing).
• Set Proxy ARP to Enable (on the near-end node).
Step 6 Leave all other settings as default and select .
The new PPP/IP instance is listed under the Management Links to Module
Management Channels blade.
Step 7 Click Add Connection.
The DCN Connection Cross window opens.
Step 8 Enter these settings:
• Set Identifier to the newly created PPP/IPinstance from the drop-down
list.
• Set Management Channel to the GCC0 entry from the drop-down list.
Step 9 Confirm with .
Expanding the "+" adjacent to the PPP/IP entry displays the DCN cross
connection.
Step 10 Select the PPP/IP entry.
The Configure Details window opens.
Step 11 Change the Admin State to Disabled, confirm with and verify with
.
Step 12 Change the Admin State to In Service, confirm with and verify with
.
Step 13 Repeat this procedure for the far-end node, but set Proxy ARPto Disable.
FSP 3000R7 Maintenance and Troubleshooting Manual - Product Release 16.2 - Document Issue A 573
