Adva FSP 3000R7 - Real Time Measurements

Performance Monitoring at the Physical Layer
Physical Parameter Unit
Current mA
Optical Power Rx dBm
Optical Power Tx dBm
OSC Gain dB
Back Reflection Rx dB
Pump Power dBm
OSC Power Rx dBm
Estimated Gain dB
Dispersion Compensation ps/nm
Link Attenuation dB
Table 98: Monitored Physical Layer Parameters
Real Time Measurements
The network element system measures the physical layer parameters listed in Table 99.
The parameters that are measured on a module, or port, depends on the module type. The
Management Data Guide provides a per module overview of which parameters are
measured and whether they are measured at the module or port. These parameters are
not recorded.
Physical Parameter Unit Description
Laser Bias Current mA Real time Laser Bias Current
Laser Bias Current Average mA Averaged Laser Bias Current 10
second window
Temperature °C Module or Plug Temperature
Temperature 2 °C Temperature second monitored
point
Laser Temperature °C Real time Laser Temperature
Current mA
Pump Power dBm
Pump-{1|2} Laser Temp °C
Pump-{1|2} Laser Bias Current mA
Attenuation dB
Table 99: Instantaneous Measurement Parameters
640 FSP 3000R7 Maintenance and Troubleshooting Manual - Product Release 16.2 - Document Issue A
