Adva FSP 3000R7 - LED Status of the 10 TCE-PCN-10 G+100 G(-GF)

Troubleshooting Enterprise Type TDM Channel Modules
Note
The module should lose power for at least 10seconds to allow any and all capacitance to
dissipate before it is reinserted.
LED
Name
LED
Colors
Potential Cause Solution for Troubleshooting
All LEDs Red A serious error in card initialization. Remove and reinsert the module. If the
condition continues, the module should
be returned to ADVA Optical Networking
for repair.
P Yellow Power is abnormal.
Off Power failure
Green Power is OK. No action is required.
Mod Yellow
blinking to
off
Management communication to the
module has failed.
1 Check the SCU firmware version
and compare it to the SCU firmware
version as listed on the NCU. If they
are different, update the SCU
firmware as described in “Performing
Other Software Update Actions” on
p.628.
2 Remove and insert the module.
If the LED is still blinking yellow to off,
contact your ADVA Optical Networking
Technical Services Representative.
Off Module admin state is disabled. 1 In the case that the module is
installed and provisioned, check the
admin state settings.
2 If the module admin state is set to
“Disabled”, change it to “In Service”,
“Management” or “Maintenance”. For
information when to use these admin
states and what they mean, refer to
the System Description,
Management chapter.
Module admin state is unassigned. 1 If the management displays “UAS”
(unassigned), check if the module is
provisioned.
2 If required provision the module.
Green Module is provisioned, admin state
is set to “Maintenance”,
“Management” or “In Service”
No action is required.
Cx Red SFP transceiver was inserted and
interface provisioned, then the SFP
transceiver was removed.
Reinsert the SFP transceiver module.
Table 57: LED Status of the 10TCE-PCN-10G+100G(-GF)
