Troubleshooting Access Type WDM Channel Modules
Note
Before you start with troubleshooting, ensure that the current firmware package is installed on the WCA-PCN-2G5U module. For details on updating
module firmware, refer to “Updating the NE Software Release” on p.617 and “Performing Other Software Update Actions” on p.628.
Note
Before you start with troubleshooting, ensure that the admin status on the affected module is configured to “Maintenance”.
CAUTION
The use of pluggable transceivers other than those approved by ADVA Optical Networking will result in loss of safety approval for the FSP 3000R7.
Pluggable transceivers not approved by ADVA Optical Networking will not function properly. Depending on the channel module type, Rx and Tx of the
affected interfaces may be disabled automatically or not. Only approved pluggable transceivers will guarantee the behavior in conjunction with the channel
module as specified.
Note
If your module has an LED status that is not represented in Table 49 on p.288, please contact your ADVA Optical Networking Technical Services
Representative.
The WCA-PCN-2G5U provides eight LEDs on the faceplate:
• “On” to indicate the power supply status
• “LP” to indicate the looping back on the client or network interfaces
• “C/T”, “C/R”, “NW/T”, “NE/T”, “NW/R” and “NE/R” to indicate the interface status
The steps in this subsection may need to be completed on both sides of the link. Please follow the troubleshooting steps in Table 49 on p.288 based upon the states of the
LEDs.
Note
When a module is removed, it should not be reinserted for at least 10 seconds to allow all power on the module to dissipate.
FSP 3000R7 Maintenance and Troubleshooting Manual - Product Release 16.2 - Document Issue A 287
