Adva FSP 3000R7 - Page 4

Shelves and Power Supply Units 59
Troubleshooting Shelves 60
SH1HU-F/2DC, SH1HU-HP/2DC and SH1HU-HP/E-TEMP/2DC Shelf LEDs 60
SH1HU-F/2DC, SH1HU-HP/2DC, and SH1HU-HP/E-TEMP/2DC Fan Status LED 62
SH1HU-F/2DC, SH1HU-HP/2DC, and SH1HU-HP/E-TEMP/2DCSlot Status LEDs 63
SH1HU-F/2DC, SH1HU-HP/2DC, and SH1HU-HP/E-TEMP/2DC Power Status LEDs 65
SH1HU-F/2DC, SH1HU-HP/2DC, and SH1HU-HP/E-TEMP/2DCNetwork Element Status
LEDs 66
SH1HU-R(/PF) Shelf LEDs 68
SH1HU-R(/PF) Fan Status LED 69
SH1HU-R(/PF) Slot Status LEDs 70
SH1HU-R(/PF) Power Status LEDs 72
SH1HU-R(/PF) Network Element Status LEDs 73
SH7HU(-R) Shelf LEDs 75
SH7HU(-R) Fan Status LEDs 76
SH7HU(-R) Slot Status LEDs 77
SH7HU(-R) Network Element Status LEDs 79
SH9HU and SHX9HU Shelf LEDs 81
SH9HU and SHX9HU Fan Status LEDs 82
SH9HU and SHX9HU Slot Status LEDs 83
SH9HU and SHX9HU Network Element Status LEDs 85
OTDR Shelf LEDs 87
Troubleshooting Power Supply Units 88
PSU/1HU-R-AC and PSU/1HU-R-DC-200 89
PSU/7HU-AC and PSU/9HU-AC 90
PSU/7HU-DC, PSU/7HU-DC-HP, PSU/7HU-DC-800, PSU/X9HU-DC-800, and PSU/9HU-DC 91
PSU/7HU-R-DC 92
Core Type Channel Modules 95
Troubleshooting Core Type TDM Channel Modules 96
4TCC-PCN-2G1U+2G5 97
4TCC-PCTN-2G7+10G 104
4TCC-PCTN-10G+40G-L#DC 111
10TCC-PCN-2G7US+10G 120
10TCC-PCTN-4GU(S)+10G 127
10TCC-PCTN-10G+100GB and 10TCC-PCTN-10G+100GC 134
10TCC-PCN-3GSDI+10G 143
10TCC-PCN-40GU+100G 150
16TCC-PCN-4GUS+10G 157
Troubleshooting Core Type WDM Channel Modules 165
2TWCC-PCN-2G7U 166
2WCC-PCN-10G 173
4WCC-PCN-10G 180
WCC-PC1N-2G7U 187
WCC-PCTN-10G 194
WCC-PCTN-100G(A,B) 202
WCC-PCN-100G 210
WCC-TN-40G-L#DC 220
10WXC-PCN-10G 226
4 FSP 3000R7 Maintenance and Troubleshooting Manual - Product Release 16.2 - Document Issue A
