106 1100 Series FD Reference Manual
4 Troubleshooting and Test Functions
Using the Control Module
1 Create the methods WLEMTEST and WLEXTEST as listed Table 20 on
page 109.
2 Copy the methods to your PC card and re-boot the control module.
3 On the Analysis screen press the Method button and copy the methods into
the module.
4 Load the method WLEXTEST. The FLD will change into the multi-emission
mode and scan in the range of the expected maximum of 397 nm
±20 nm.
Figure 35 Excitation Spectrum
Figure 36 Copying Methods into the FLD
