2-110 Chapter 2
System Verification and Performance Tests
Agilent 8753ET System Verification and Performance Tests
NOTE The analyzer’s calibration factor sensor table can hold a maximum of 55
calibration factor data points.
The following softkeys are included in the sensor calibration factor entries menu:
press to select a point where you can use the front panel knob or entry
keys to enter a value.
press to edit or change a previously entered value.
press to delete a point from the sensor calibration factor table.
select this key to add a point into the sensor calibration factor table.
select this key to erase the entire sensor calibration factor table.
select this key when done entering points to the sensor calibration
factor table.
As an example, the following are the keystrokes for entering the first two calibration
factor data points for the 8482A power sensor (assuming CF% = 96.4 at 100 kHz and
CF% = 98.4 at 300 kHz):
a. From the sensor calibration factor entries menu, press .
b. Press . If you make an entry error, press and
re-enter the correct value again.
c. Press .
d. Press to terminate the first calibration factor data point entry.
e. To enter the second cal factor data point, press .
f. Press .
g. Press .
h. To terminate the second calibration factor data point entry, press .
i. Press and use the front panel knob to scroll through the sensor
calibration factors table. Check to be sure all values are entered correctly. If you see
an error, use the front panel knob to point to the data point you want to modify and
press .
12.Press the appropriate softkeys to create a power sensor calibration factors table.
13.Press to exit the sensor calibration factor entries menu.
14.Press to start the power meter
calibration. (The Port 1 Cal Power is 0 dBm, the reference power level for power
linearity measurements.)
100 k/m
96.4 x1
300 k/m
98.4 x1
