Chapter 2 2-147
System Verification and Performance Tests
Agilent 8753ES Performance Test Records
Agilent Technologies Company
Model 8753ES
Serial Number
Report Number
Option(s) Date
5. Minimum R Channel Level
Note: If your analyzer does not have Option 006, write “N/A” in all entries above 3 GHz.
CW Frequency Specification
(dBm)
Test Port Power
(R Channel Power)
Measurement
Uncertainty
(dB)
300 kHz < −35 ± 1.0
3.29 MHz < −35 ± 1.0
3.31 MHz < −35 ± 1.0
15.90 MHz < −35 ± 1.0
16.10 MHz < −35 ± 1.0
30.90 MHz < −35 ± 1.0
31.10 MHz < −35 ± 1.0
1.6069 GHz < −35 ± 1.0
1.6071 GHz < −35 ± 1.0
3.000 GHz < −35 ± 1.0
4.000 GHz < −30 ± 2.0
5.000 GHz < −30 ± 2.0
6.000 GHz < −30 ± 2.0
