Page #178 background image
2-152 Chapter 2
System Verification and Performance Tests
Agilent 8753ES Performance Test Records
Agilent Technologies Company
Model 8753ES
Serial Number
Report Number
Date
9. Uncorrected Port Performance (continued)
Note: If your analyzer does not have Option 006, write “N/A” in all entries above 3 GHz.
Test Description Frequency Range Spec.
(dB)
Measured Value
(dB)
Meas.
Uncert. (dB)
Reverse Direction
Directivity 300 kHz–1.3 GHz ≤ −35 ±0.9
Directivity 1.3 GHz–3 GHz ≤ −30 ±0.8
Directivity 3 GHz–6 GHz ≤ −25 ±0.8
Reverse Direction
Source Match 300 kHz–1.3 GHz ≤ −16 ±0.2
Source Match 1.3 GHz–3 GHz ≤ −16 ±0.2
Source Match 3 GHz–6 GHz ≤ −14 ±0.3
Reverse Direction
Refl. Tracking 300 kHz–1.3 GHz ±1.0 ±0.001
Refl. Tracking 1.3 GHz–3 GHz ±1.0 ±0.005
Refl. Tracking 3 GHz–6 GHz ±1.5 ±0.020
Forward Direction
Trans. Tracking 300 kHz–1.3 GHz ±1.0 ±0.006
Trans. Tracking 1.3 GHz–3 GHz ±1.0 ±0.009
Trans. Tracking 3 GHz–6 GHz ±1.5 ±0.021
