Agilent Technologies 8753ET Service Guide

Chapter 2 2-153
System Verification and Performance Tests
Agilent 8753ES Performance Test Records
Agilent Technologies Company
Model 8753ES
Serial Number
Report Number
10. System Trace Noise
Ratio IF BW Phase/Magnitude Measured Value Specification
Test Frequency: 3 GHz
A/R 10 Hz Magnitude < 0.001 dB rms
A/R 10 Hz Phase < 0.006 °rms
A/R 3 kHz Phase < 0.038 °rms
A/R 3 kHz Magnitude < 0.006 dB rms
B/R 3 kHz Magnitude < 0.006 dB rms
B/R 3 kHz Phase < 0.038 °rms
B/R 10 Hz Phase < 0.006 °rms
B/R 10 Hz Magnitude < 0.001 dB rms
Test Frequency: 6 GHz
Note: If your analyzer does not have Option 006, write “N/A” in all entries above 3 GHz.
A/R 10 Hz Magnitude < 0.002 dB rms
A/R 10 kHz Phase < 0.012 °rms
A/R 3 kHz Phase <0.070 °rms
A/R 3 Hz Magnitude < 0.010 dB rms
B/R 3 kHz Magnitude < 0.010 dB rms
B/R 3 kHz Phase < 0.070 °rms
B/R 10 Hz Phase < 0.012 °rms
B/R 10 Hz Magnitude < 0.002 dB rms
