Agilent Technologies 8753ET Service Guide

2-154 Chapter 2
System Verification and Performance Tests Agilent 8753ES Performance Test Records
Agilent Technologies Company
Model 8753ES
Serial Number
Report Number
Option(s) Date
11. Test Port Receiver Magnitude Dynamic Accuracy (Test Port 2)
GF|G − F|
Test
Port
Input
Power
(dBm)
8496A
Attn.
(dB)
Real Part Imag. Part Test Port
Measurement
(dB)
Expected
Measurement
(Corrected)
(dB)
Dynamic
Accuracy
(Calculated)
Spec.
(dB)
Meas.
Uncer.
(dB)
−10 0 ≤ 0.033 ± 0.008
−20
(ref)
10 0.000 ≤ 0.021 ± 0.008
−30 20 ≤ 0.031 ± 0.008
−40 30 ≤ 0.041 ± 0.008
−50 40 ≤ 0.054 ± 0.008
−60 50 ≤ 0.069 ± 0.017
−70 60 ≤ 0.111 ± 0.017
−80 70 ≤ 0.257 ± 0.017
−90 80 ≤ 0.741 ± 0.017
−100 90 ≤ 2.121 ± 0.027
