Agilent 8753ES Performance Test Records
Agilent Technologies Company
Model 8753ES
Serial Number
Report Number
Option(s) Date
11. Test Port Receiver Magnitude Dynamic Accuracy (Test Port 1)
GF|G − F|
Test
Port
Input
Power
(dBm)
8496A
Attn.
(dB)
Real Part Imaginary Part Test Port
Measurement
(dB)
Expected
Measurement
(Corrected)
(dB)
Dynamic
Accuracy
(Calculated)
Spec.
(dB)
Meas.
Uncer.
(dB)
−10 0 ≤ 0.033 ± 0.008
−20
(ref)
10 0.000 ≤ 0.021 ± 0.008
−30 20 ≤ 0.031 ± 0.008
−40 30 ≤ 0.041 ± 0.008
−50 40 ≤ 0.054 ± 0.008
−60 50 ≤ 0.069 ± 0.017
−70 60 ≤ 0.111 ± 0.017
−80 70 ≤ 0.257 ± 0.017
−90 80 ≤ 0.741 ± 0.017
−100 90 ≤ 2.121 ± 0.027
