2-156 Chapter 2
System Verification and Performance Tests
Agilent 8753ES Performance Test Records
Agilent Technologies Company
Model 8753ES
Serial Number
Option(s)
12. Test Port Receiver Magnitude Compression
Note: If your analyzer does not have Option 006, write “N/A” in all entries above 3 GHz.
Measured Value
CW Frequency Test Port 2 Test Port 1 Specification
(dB)
Measurement
Uncertainty
(dB)
300 kHz ≤ 0.42 ±0.04
50 MHz ≤ 0.42 ±0.04
1 GHz ≤ 0.42 ±0.04
1.65 GHz ≤ 0.42 ±0.04
2 GHz ≤ 0.42 ±0.04
3 GHz ≤ 0.42 ±0.04
4 GHz ≤ 0.76 ±0.05
5 GHz ≤ 0.76 ±0.05
6 GHz ≤ 0.76 ±0.05
