Chapter 2 2-157
System Verification and Performance Tests
Agilent 8753ES Performance Test Records
Agilent Technologies Company
Model 8753ES
Serial Number
Report Number
Option(s) Date
13. Test Port Receiver Phase Compression
Note: If your analyzer does not have Option 006, write “N/A” in all entries above 3 GHz.
Measured Value
CW Frequency Test Port 2 Test Port 1 Specification Measurement
Uncertainty
300 kHz ≤ 6°±0.3°
50 MHz ≤ 6°±0.3°
1 GHz ≤ 6°±0.3°
1.65 GHz ≤ 6°±0.3°
2 GHz ≤ 6°±0.3°
3 GHz ≤ 6°±0.3°
4 GHz ≤ 7.2°±0.4°
5 GHz ≤ 7.2°±0.4°
6 GHz ≤ 7.2°±0.4°
