Agilent 8753ES Performance Test Records
Agilent Technologies Company
Model 8753ES
Serial Number
Report Number
Date
15. Harmonic Measurement Accuracy (Option 002 only)
Note: If your analyzer does not have Option 006, write “N/A” in all entries above 3 GHz.
Analyzer
Freq.
(Fund.)
Ext.
Source
Freq.
(Harm.)
Power
Meter
Meas.
Cable
Loss
(A)
Power
Meter +
Cable
Loss
(B)
Network
Analyzer
Reading
(A − B)
Harm.
Meas.
Accy.
Spec.
(dB)
Meas.
Uncert.
(dB)
20 MHz 40 MHz ± 1.5 ± 0.17
20 MHz 60 MHz ± 1.5 ± 0.17
100 MHz 200 MHz ± 1.5 ± 0.17
100 MHz 300 MHz ± 1.5 ± 0.17
300 MHz 600 MHz ± 1.5 ± 0.17
300 MHz 900 MHz ± 1.5 ± 0.17
500 MHz 1 GHz ± 1.5 ± 0.17
500 MHz 1.5 GHz ± 1.5 ± 0.17
1 GHz 2 GHz ± 1.5 ± 0.17
1 GHz 3 GHz ± 1.5 ± 0.17
2 GHz 4 GHz ± 3 ± 0.17
2 GHz 6 GHz ± 3 ± 0.17
3 GHz 6 GHz ± 3 ± 0.17
