Agilent Technologies 8753ET Service Guide

2-166 Chapter 2
System Verification and Performance Tests
Agilent 8753ET Performance Test Records
4. Reflection Test Port Output Power Linearity (for analyzers without Option 004)
(continued)
Frequency Range: 3 GHz to 6 GHz
Note: If your analyzer does not have Option 006, write “N/A” in all entries above 3 GHz.
Power Setting
(dBm)
Power Offset
(dBm)
Marker 1
(Maximum)
Marker 2
(Minimum)
Spec.
(dB)
Meas.
Uncert.
(dB)
−20 −15 ±0.5 ±0.04
−18 −13 ±0.5 ±0.03
−16 −11 ±0.5 ±0.03
−14 −9 ±0.2 ±0.03
−12 −7 ±0.2 ±0.03
−10 −5 ±0.2 ±0.03
−8 −3 ±0.2 ±0.02
−6 −1 ±0.2 ±0.02
−4+1 ±0.2 ±0.02
−2+3 ±0.2 ±0.02
0+5 ±0.5 ±0.03
+3 +8 ±0.5 ±0.03
+5 +10 ±0.5 ±0.03
