Chapter 2 2-165
System Verification and Performance Tests
Agilent 8753ET Performance Test Records
Agilent Technologies
Company
Model 8753ET
Serial Number
Report Number
Option(s) Date
4. Reflection Test Port Output Power Linearity (for analyzers without Option 004)
Frequency Range: 300 kHz to 3 GHz
Power Setting
(dBm)
Power Offset
(dBm)
Marker 1
(Maximum)
Marker 2
(Minimum)
Spec.
(dB)
Meas.
Uncert.
(dB)
−20 −15 ±0.5 ±0.04
−18 −13 ±0.5 ±0.03
−16 −11 ±0.5 ±0.03
−14 −9 ±0.2 ±0.03
−12 −7 ±0.2 ±0.03
−10 −5 ±0.2 ±0.03
−8 −3 ±0.2 ±0.02
−6 −1 ±0.2 ±0.02
−4+1 ±0.2 ±0.02
−2+3 ±0.2 ±0.02
0+5 ±0.5 ±0.03
+3 +8 ±0.5 ±0.03
+5 +10 ±0.5 ±0.03
