2-164 Chapter 2
System Verification and Performance Tests
Agilent 8753ET Performance Test Records
Agilent Technologies Company
Model 8753ET
Serial Number
Report Number
Option(s) Date
3. Reflection Test Port Output Power Level Accuracy
Note: If your analyzer does not have Option 006, write “N/A” for entries above 3 GHz.
Test Frequency Minimum
Value
a
(dBm)
a. Values in parentheses pertain to analyzers with Option 004.
Measured
Value
Maximum
Value
a
(dBm)
Measurement
Uncertainty
(dB)
300 kHz −6.0 (−11.0) −4.0 (−9.0) ±0.47
20 MHz −6.0 (−11.0) −4.0 (−9.0) ±0.25
50 MHz −6.0 (−11.0) −4.0 (−9.0) ±0.12
100 MHz −6.0 (−11.0) −4.0 (−9.0) ±0.12
200 MHz −6.0 (−11.0) −4.0 (−9.0) ±0.12
500 MHz −6.0 (−11.0) −4.0 (−9.0) ±0.12
1 GHz −6.0 (−11.0) −4.0 (−9.0) ±0.12
2 GHz −6.0 (−11.0) −4.0 (−9.0) ±0.15
3 GHz −6.0 (−11.0) −4.0 (−9.0) ±0.15
4 GHz −6.0 (−11.0) −4.0 (−9.0) ±0.17
5 GHz −6.0 (−11.0) −4.0 (−9.0) ±0.17
6 GHz −6.0 (−11.0) −4.0 (−9.0) ±0.17
