Chapter 2 2-169
System Verification and Performance Tests
Agilent 8753ET Performance Test Records
Agilent Technologies Company
Model 8753ET
Serial Number
Report Number
Option(s) Date
6. Minimum R Channel Level
Note: If your analyzer does not have Option 006, write “N/A” in all entries above 3 GHz.
CW Frequency R Channel Power Specification
(dBm)
Measurement
Uncertainty
(dB)
300 kHz < −35 ±1.5
3.29 MHz < −35 ±1.5
3.31 MHz < −35 ±1.5
15.90 MHz < −35 ±1.5
16.10 MHz < −35 ±1.5
30.90 MHz < −35 ±1.5
31.10 MHz < −35 ±1.5
1.6069 GHz < −35 ±1.5
1.6071 GHz < −35 ±1.5
3.000 GHz < −30 ±1.5
4.000 GHz < −30 ±1.5
5.000 GHz < −30 ±1.5
6.000 GHz < −30 ±1.5
