Chapter 10 10-5
Service Key Menus and Error Messages
Service Key Menus
Table 10-2 Tests Menu Keys
Key GPIB
Mnemonic
Description
EXET Runs the selected test and may display these softkeys:
(
TESR1) continues the selected test.
(
TESR2) alters correction constants during
adjustment tests.
(
TESR4) displays the next choice.
(
TESR6) chooses the option indicated.
(
TESR8) terminates the test and returns to
the tests menu.
N/A Evaluates the analyzer’s internal operation. These tests are
completely internal and do not require external connections
or user interaction.
N/A Evaluate the analyzer’s external operation. These additional
tests require some user interaction (such as keystrokes).
N/A Verifies the analyzer system operation by examining the
contents of the measurement calibration arrays. Refer to
Chapter 2 , “System Verification and Performance
Tests.”
Information about the calibration arrays is provided
in
Chapter 11 , “Error Terms.
N/A Generates and stores the correction constants. For more
information, refer to
Chapter 3 , “Adjustments and
Correction Constants.”
N/A Checks for correct operation of the display and GSP board.
EXECUTE TEST
CONTINUE
YES
NEXT
SELECT
ABORT
INTERNAL TESTS
EXTERNAL TESTS
SYS VER TESTS
ADJUSTMENT TESTS
DISPLAY TESTS
