Agilent Technologies 8753ET Service Guide

2-46 Chapter 2
System Verification and Performance Tests
Agilent 8753ES System Verification and Performance Tests
Figure 2-26 8753ES Crosstalk Baseline Measurement
2. Press .
3. Press .
4. Press (or, for
analyzers with Option 014 or Option 075, press ).
5. Press .
6. Press .
7. Press . Wait for the sweep to finish, as
indicated by the Hld notation on the left side of the display.
8. Press .
9. Press .
10.Press . Wait for the sweep to finish, as
indicated by the Hld notation on the left side of the display.
11.Press .
12.Press .
13.Press
.
Preset Cal
MORE
ALTERNATE A and B
Start 300 k/m Stop 3 G/n
Sweep Setup
NUMBER of POINTS
101 x1 Power 10 x1
8 x1
Avg
IF BW
10 x1
Meas
Trans: FWD S21 (B/R)
Sweep Setup
TRIGGER MENU
SINGLE
Display
DATA → MEMORY
DATA/MEM
Chan 2 Meas
Trans: REV S12 (A/R)
Sweep Setup
TRIGGER MENU
SINGLE
Display
DATA → MEMORY
DATA/MEM
Scale Ref
SCALE/DIV
10
x1
REFERENCE VALUE
−100 x1
Chan 1 Scale Ref
SCALE/DIV
10 x1
REFERENCE VALUE
−100
x1
