Chapter 2 2-55
System Verification and Performance Tests
Agilent 8753ES System Verification and Performance Tests
Source Match (Reverse) Calibration Coefficient
64.Press . At the prompt, press
.
65.When the analyzer finishes the test, repeat steps 58 through 61.
Reflection Tracking (Reverse) Calibration Coefficient
66.Press .
67.When the test is done, press .
68.Using the front panel knob to move the marker along the data trace, locate the
maximum and minimum values for the 300 kHz to 1.3 GHz frequency range.
69.Enter the data trace value that is of greater deviation from zero into the performance
test record. (This is the greater absolute value of either the maximum data trace value
or the minimum data trace value.)
70.Repeat the previous three steps for the other frequency ranges listed on the
performance test record.
Transmission Tracking (Forward) Calibration Coefficient
71.Press .
72.When the analyzer finishes the test, repeat steps 67 through 70.
System
39 x1
System
40 x1
Marker
System
37 x1
