Chapter 2 2-57
System Verification and Performance Tests
Agilent 8753ES System Verification and Performance Tests
Figure 2-33 System Trace Noise Test Setup
2. Press
.
3. Press to activate the
instrument’s statistics feature.
A/R Trace Noise Magnitude IF BW = 10 Hz
4. Press .
5. Press .
6. Press . Wait for the
sweeps to finish as indicated by the Hld notation on the left side of the display.
7. Write the s.dev (standard deviation) value shown, which appears on the analyzer
display, on the performance test record.
A/R Trace Noise Phase IF BW = 10 Hz
8. Press .
9. Write the s.dev value, which appears on the analyzer display, on the performance test
record.
A/R Trace Noise Phase IF BW = 3 kHz
10.Press .
11.Press . Wait for the
sweeps to finish as indicated by the Hld notation on the left side of the display.
12.Write the s.dev value on the performance test record.
Preset Power 5 x1 Sweep Setup
NUMBER of POINTS
101 x1
CW FREQ
3 G/n
Marker Fctn
MARKER MODE MENU
MKR STATS ON
Avg
IF BW
10 x1
Meas
Trans: REV S12 (A/R)
Sweep Setup
TRIGGER MENU
NUMBER OF GROUPS
3 x1
Format
PHASE
Avg
IF BW
3 k/m
Sweep Setup
TRIGGER MENU
NUMBER OF GROUPS
3 x1
