2-58 Chapter 2
System Verification and Performance Tests
Agilent 8753ES System Verification and Performance Tests
A/R Trace Noise Magnitude IF BW = 3 kHz
13.Press .
14.Write the s.dev value on the performance test record.
B/R Trace Noise Magnitude IF BW = 3 kHz
15.Press
. Wait for the sweep to finish as indicated by the Hld
notation on the left side of the display.
16.Write the s.dev value on the performance test record.
B/R Trace Noise Phase IF BW = 3 kHz
17.Press .
18.Write the s.dev value on the performance test record.
B/R Trace Noise Phase IF BW = 10 Hz
19.Press
. Wait for the sweep to finish as indicated by the Hld
notation on the left side of the display.
20.Write the s.dev value on the performance test record.
B/R Trace Noise Magnitude IF BW = 10 Hz
21.Press .
22.Write the s.dev value on the performance test record.
Option 006 only:
1. Press .
2. Go back to “A/R Trace Noise Magnitude IF BW = 10 Hz” on page 2-57, and perform this
entire procedure again. Record all values in the performance test record under “Test
Frequency 6 GHz.”
In Case of Difficulty
1. Perform the ADC Offset Correction Constants procedure, located in Chapter 3 ,
“Adjustments and Correction Constants.”
2. Repeat this performance test.
3. Suspect the A10 Digital IF board assembly if the analyzer still fails the test.
Format
LOG MAG
Meas
Trans: FWD S21 (B/R)
Sweep Setup
TRIGGER MENU
NUMBER OF GROUPS
3 x1
Format
PHASE
Avg
IF BW
10 x1 Sweep Setup
TRIGGER MENU
NUMBER OF GROUPS
3 x1
Format
LOG MAG
Sweep Setup
CW FREQ
6 G/n
