240 Chapter5
Language Reference
MEASure Group of Commands
(For cdma2000
and W-CDMA
the data is only
available with
spectrum
display selected)
4
Basic,
cdmaOne,
cdma2000,
W-CDMA
(3GPP), or
W-CDMA
(Trial &
Arib) mode
Returns the frequency-domain spectrum trace data for the
entire frequency range being measured.
With the spectrum view selected
(DISPlay:ACP:VIEW SPECtrum) and the spectrum trace on
(SENSe:ACP:SPECtrum:ENABle):
• In FFT mode (SENSe:ACP:SWEep:TYPE FFT) the number
of trace points returned are 343 (cdma2000) or 1715
(W-CDMA). This is with the default span of 5 MHz
(cdma2000) or 25 MHz (W-CDMA). The number of points
also varies if another offset frequency is set.
• In sweep mode (SENSe:ACP:SWEep:TYPE SWEep), the
number of trace points returned is 601 (for cdma2000 or
W-CDMA) for any span.
With bar graph display selected, one point of –999.0 will be
returned.
5
iDEN
mode
Returns 4 comma-separated relative power values for the
reference and offset channels:
1. Reference channel − relative power
2. Reference channel − relative power (duplicate of above)
3. Lower offset channel − relative power
4. Upper offset channel − relative power
Total power
reference
5
Basic,
cdmaOne,
cdma2000,
W-CDMA
(3GPP), or
W-CDMA
(Trial &
Arib) mode
Returns 12 comma-separated scalar values (in dBm) of the
absolute power of the center and the offset frequencies:
1. Upper adjacent chan center frequency
2. Lower adjacent chan center frequency
3. Negative offset frequency (1)
4. Positive offset frequency (1)
...
11.Negative offset frequency (5)
12.Positive offset frequency (5)
Power spectral
density
reference
5
Basic,
cdmaOne,
cdma2000,
W-CDMA
(3GPP), or
W-CDMA
(Trial &
Arib) mode
Returns 12 comma-separated scalar values (in dBm/Hz) of the
absolute power of the center and the offset frequencies:
1. Upper adjacent chan center frequency
2. Lower adjacent chan center frequency
3. Negative offset frequency (1)
4. Positive offset frequency (1)
...
11.Negative offset frequency (5)
12.Positive offset frequency (5)
Measurement
Type
n Results Returned
To Next Page
