5 AWGN Waveform Generator

This chapter contains examples for using the additive white gaussian noise (AWGN) waveform generator.

The AWGN waveform generator is available only for the E4438C Vector Signal Generator with

Option 001/601or 002/602 and Option 403:

• “Arb Waveform Generator AWGN” on page 202

• “Real Time I/Q Baseband AWGN” on page 203

For adding real-time AWGN to waveforms using the Dual ARB player, see “Adding Real-Time Noise to a

Dual ARB Waveform (Option 403)” on page 111

Table of Contents

Other manuals for Agilent Technologies E4438C

Programming Guide366 pages

Datasheet40 pages

Configuration Guide12 pages

Installation Note18 pages

User's & Service Guide26 pages

Questions and Answers:

L
Leonard WeberJul 25, 2025
What to do if I get ERROR 628, DAC over range on my Agilent Technologies Inverter?
- B
  Brittney RossJul 26, 2025
  The 'ERROR 628, DAC over range' on your Agilent Technologies Inverter can occur due to a couple of reasons. One reason is that the signal's amplitude is exceeding the DAC input range, in which case you should scale or reduce the DAC input values. Another reason, specifically on the Agilent MXG, is downloading an encrypted file (.SECUREWAVE) from a PC or USB with an incorrect suffix. If this is the case, use the Use as or Copy File to Instrument softkey menus to correctly download the encrypted file to the instrument.
J
John RamirezAug 2, 2025
How to fix ERROR -321, Out of memory on Agilent Technologies Inverter?
- J
  justindownsAug 2, 2025
  If you're encountering 'ERROR -321, Out of memory' on your Agilent Technologies Inverter, it means there isn't enough space in the ARB memory for the waveform file you're trying to download. To resolve this, either reduce the file size of the waveform file or delete unnecessary files from the ARB memory.
C
charlene71Aug 9, 2025
Why is there no RF output from my Agilent Technologies Inverter?
- K
  Kenneth PierceAug 9, 2025
  If your Agilent Technologies Inverter has no RF output, the marker RF blanking function might be active. Check and turn RF blanking off to restore the output.
