215
7 Digital Signal Interface Module
This chapter provides information on the N5102A Baseband Studio Digital Signal Interface Module. These
features are available only in E4438C ESG Vector Signal Generators with Options 003/004 and 601/602.
Functions, features and operation of the N5102A are explained and demonstrated.
• “Clock Timing” on page 216
• “Data Types” on page 232
• “Connecting the Clock Source and the Device Under Test” on page 230
• “Operating the N5102A Module in Output Mode” on page 234
• “Operating the N5102A Module in Input Mode” on page 243
