Chapter 7 225

Digital Signal Interface Module

Clock Timing

1 Sample Period

4 Clocks Per Sample

4 Clocks

Sample rate decreases by a factor of four

I sample

Q sample

Clock

4 bits per word

4 bits per word

1 Sample Period

2 Clocks Per Sample

2 Clocks

I sample

Q sample

Sample rate decreases by a factor of two

Clock

4 bits per word

4 bits per word
