62 Chapter 3
Basic Operation
Creating and Applying User Flatness Correction
Configure the Power Meter
1. Select SCPI as the remote language for the power meter.
2. Zero and calibrate the power sensor to the power meter.
3. Enter the appropriate power sensor calibration factors into the power meter as appropriate.
4. Enable the power meter’s cal factor array.
NOTE For operating information on your particular power meter/sensor, refer to its operating
guide.
Connect the Equipment
Connect the equipment as shown in Figure 3-5 on page 63.
NOTE During the process of creating the user flatness correction array, the power meter is
controlled by the signal generator via GPIB. No other controllers are allowed on the GPIB
interface.
