3 Sample Sessions: Measuring a Trace How to Save the Measurement
104 E6000C Mini-OTDR User’s Guide, E0302
For details about connecting an external printer, see
“External connections” on page 70 and “How to Print the
Measurement” on page 100.
How to Save the Measurement
What is saved Saving a measurement not only saves the results, but also
saves the parameter measurement, event table, and
horizontal offset.
When you recall the measurement later, you can do
further analyzing, or compare it with other
measurements. You can also repeat the measurement
using exactly the same parameters as the first time.
To save the measurement on the Mini-OTDR’s internal
memory:
1 Select [F
ILE] from the popup panel.
2 Cursor D
OWN to the <SAVE AS...> option. and press
S
ELECT. You see a screen listing the current files on the
device.
