1 Getting Started The Mini-OTDR module
38 E6000C Mini-OTDR User’s Guide, E0302
Adding a Connector Interface
Figure 5 Adding a Connector Interface
Before you add the connector interface, you must have
inserted a module to your Mini-OTDR.
On the left of the module when viewed from behind, you
see an Optical Output Connector (see Figure 5).
NOTE Before you attach a connector and fiber, you should clean
them both.
See “How to clean connectors” on page 284 and “How to
clean bare fiber adapters” on page 288.
Insert the Connector Interface into the Optical Output
Connector. You can now attach a fiber to the Connector
Interface.
