How to Add a Landmark or Event Comment 4 Sample Sessions: Analyzing an Existing Trace
E6000C Mini-OTDR User’s Guide, E0302
109
If you select No, you see an empty text field where you can
add a new landmark name. If you select Yes, the edit field
contains the text for the existing landmark.
Figure 36 Landmark text box
Add landmark name 5 Use the screen keyboard to add a landmark name.
Move to the letters you want, and press the S
ELECT key.
Move to Del to delete the previous character, and to
CAPS to change the case of subsequent letters
6 When you have finished the Landmark text, move to OK
and press the S
ELECT key.
The landmark is now shown on the Event Bar and in the
Event Table. You can specify whether the Event Bar and
Event Table are shown from the [V
IEW] menu.
NOTE You can save landmarks by selecting
[E
VENTS]<LANDMARK><SAVE AS...>.
Previously saved landmarks can be loaded by
[E
VENTS]<LANDMARK><LOAD...>
