Specifications / Characteristics I Appendix: 3-λ Module
E6000C Mini-OTDR User’s Guide, E0302
315
Submodules The E6013A does not have a slot for the E6006A Power
Meter submodule or the E6007A Visual Fault Finder
submodule.
Module Specifications / Characteristics
Notes:
1 Measured with a standard single-mode fiber at SNR=1
noise level and with 3 minutes averaging time. Optimize
mode: dynamic
2 Reflectance
≤ -35 dB at 10 ns pulsewidth, and with span
≤ 4 km, optimize mode Resolution.
Typical specification at Reflectance
≤ -35 dB at 10 ns
pulsewidth, and with span
≤ 400 m at 8 cm sample
spacing, optimize resolution.
3 Guaranteed Specification at Reflectance
≤ -35 dB at
30 ns pulsewidth, and with span
≤ 4km. Optimize mode:
resolution.
4 Typical Specification at Reflectance
≤ -50 dB at 30 ns
pulsewidth, and with span
≤ 4 km (typical value).
Module E6013A
Central Wavelength 1310
±25 nm/ 1550±25 nm/ 1625±25 nm
Applicable Fiber single-mode
Pulsewidth 10ns 100ns
1µs10µs 20µs
Dynamic Range
1
[dB]
18/17/17 23/22/22 29/28/28 36/35/35 39/38/37
Event Deadzone
2
5m (3m)
Attenuation Deadzone
3
Attenuation Deadzone
4
20/25/30 m
10/12/14m
