AC Line Power Supply Requirements A Installation and Maintenance
E6000C Mini-OTDR User’s Guide, E0302
177
AC Line Power Supply
Requirements
The Agilent E6000C can operate through the supplied AC
adapter between 100V and 240V
± 10%, at a frequency in
the range from 50 to 60 Hz. The maximum power
consumption is 30VA with all options installed.
Line Power Cable
According to international safety standards, the charger
has a three-wire power cable.
The type of power cable shipped with each instrument
depends on the country of destination. Refer to Figure 73
for the part numbers of the power cables available.
NOTE You only need to use the line power cable to connect to
the AC adapter.
Figure 73 Line Power Cables – Plug Identification
