4 Sample Sessions: Analyzing an
Existing Trace
“Sample Sessions: Measuring a Trace” on page 81
showed you how to measure a trace, and to make simple
settings.
This chapter contains further step-by step guides showing
what you can do to analyze a trace after it has been
measured.
Sample Sessions The following sample sessions show you how to:
• Add a Landmark and Event Comment,
• Add Reflective and Non-Reflective Events,
• Measure Total Loss, Reflectance, and Insertion Loss,
• Display and Compare Two Traces,
If you have not used a Mini-OTDR before, you should first
read Sample Sessions: Measuring a Trace. The equipment
used in the following Sample Sessions is the same as
before.
