C Specifications Module Specifications/Characteristics
212 E6000C Mini-OTDR User’s Guide, E0302
The guaranteed values above are tested specifications.
Agilent OTDR modules have the pulsewidths listed in
“Pulsewidth” on page 207.
Notes:
1 Measured with a standard single-mode fiber at SNR=1
noise level and with 3 minutes averaging time. Optimize
mode: dynamic
2 Reflectance
≤ -35 dB at 10 ns pulsewidth, and with span
≤ 4 km, optimize resolution.
Typical specification at Reflectance
≤ -35 dB at 10 ns
pulsewidth, and with span
≤ 400 m at 8 cm sample
spacing, optimize resolution.
3 Guaranteed Specification at Reflectance
≤ -35 dB at
30 ns pulsewidth, and with span
≤ 4 km. Optimize mode:
resolution.
Module E6008B E6012A
Central Wavelength 1310
±25 nm/ 1550±25 nm 1550±25 nm/ 1625±20 nm
Applicable Fiber single-mode single-mode
Pulsewidth 10ns 100ns
1µs10µs 20µs 10ns 100ns 1µs10µs20µs
Dynamic Range
1
[dB]
24/22 29/27 35/34 42/41 45/43 22/18 27/24 34/30 41/37
- / 40 43/ -
Event Deadzone
2
5m (3m)5m (3m)
Attenuation Deadzone
3
Attenuation Deadzone
4
20/25 m
10/12m
25/28 m
12/14m
Module E6005A E6009A
Central Wavelength 850
±30 nm / 1300±30 nm 850±30 nm / 1300±30 nm
Applicable Fiber multimode 62.5
µm multimode 62.5 µm
Pulsewidth 10ns 100ns
1µs 10µs 10ns 100ns 1µs
Dynamic Range
5
[dB] 19/17 26/22 - /28 - /34 12/12 18/18 - /23
Event Deadzone
6
3m 3m
Attenuation Deadzone
7
10 m 10 m
