D Single-Mode/Multimode Module Performance Tests Performance Test Form Sheets
246 E6000C Mini-OTDR User’s Guide, E0302
Performance Test for the Agilent E6000C with Single-mode Modules Page 3 of 8
Model Agt. __________ Module Report No. __________ Date ___________
No. Test Description
I. Dynamic Range 1310 nm Wavelength
Minimum Specification
Pulsewidth Dynamic
Range
98%
Dyn Range =
Dyn Range
98%
+ 1.9dB
E6001A
E6004A
E6003A E6003B E6008B E6013A Meas.
Uncertainty
10
µs
1
µs
100 ns
10 ns
dB
_______
_______
_______
_______
dB
_______
_______
_______
_______
dB
28
23
18
13
dB
35
30
24
19
dB
38
30
24
19
dB
42
35
29
24
dB
36
29
23
18
dB
_______
_______
_______
_______
II. Event Deadzone 1310 nm Wavelength
Event Deadzone Max Spec Meas.
Uncertainty
Return Loss
≥ 35dB
Conditions:
Meas. Span. 2km
Pulsewidth 10ns
E6001A, E6003A,
E6003B, E6004A,
E6008B, E6013A _______ m 5 m _______ m
