Safety Summary
E6000C Mini-OTDR User’s Guide, E0302
7
E6004A E6007A E6008B
1310 nm 1550 nm
Laser Type FP-Laser
InGaAsP
MQW-Laser
AlGaInP
FP-Laser
InGaAsP
FP-Laser
InGaAsP
Laser Class
According to IEC 825 (Eu-
rope)
3A 2 3A 3A
According to 21 CFR 1040.10
(Canada, Japan, USA)
12 11
Output Power (Pulse Max) 50 mW n/a 120 mW 200 mW
Pulse Duration (Max) 10
µsn/a 20 µs20 µs
Pulse Energy (Max) 500 nWs n/a 2.4
µWs 4.0 µWs
Output Power (CW) 500
µW 500 µW 500 µW 500 µW
Beam Waist Diameter 9
µm9 µm9 µm9 µm
Numerical Aperture 0.1 0.1 0.1 0.1
Wavelength 1310/
1550
±25nm
635
±10nm 1310
±25nm
1550
±25nm
E6012A
1550 nm 1625 nm
Laser Type FP-Laser
InGaAsP
FP-Laser
InGaAsP
Laser Class
According to IEC 825 (Europe) 3A 3A
According to 21 CFR 1040.10
(Canada, Japan, USA)
11
Output Power (Pulse Max) 200 mW 200 mW
Pulse Duration (Max) 20
µs20 µs
Pulse Energy (Max) 4.0
µWs 4.0 µWs
Output Power (CW) 500
µW 500 µW
Beam Waist Diameter 9
µm9 µm
Numerical Aperture 0.1 0.1
Wavelength 1550
±25nm 1625 ±20nm
