Agilent Technologies E6000C User Manual

E6000C Mini-OTDR User’s Guide, E0302 81
3
3 Sample Sessions: Measuring a Trace
Measuring a Trace contains a number of sample sessions
of step-by step guides showing how to use common
features of the Mini-OTDR.
Equipment used In these sample sessions we use:
• A Mini-OTDR Agilent Technologies E6000C with an
optical module Agilent E6003A (1310/1550 nm, single-
mode).
• A length of fiber of about 40 km, terminated at one end
with a Diamond HMS-10/Agilent connector and
unterminated at the other end. The fiber has a
refractive index of 1.462, and is to be used at a
wavelength of 1310 nm.
• A connector interface to match the connector on the
fiber being used.
Sample Sessions The following sample sessions show you how to:
• Set up your Mini-OTDR,
• Run a Measurement: Automatically, Manually, and in
Real Time,
• Use the Event Table and Pass/Fail test,
• Set the Horizontal Offset and Fiber End,
