AIREDALE DeltaChill - Range Layout

Chillers
Introduction
DeltaChill™ Air Cooled and FreeCool
10
Chiller Technical Manual 7267818 V1.13.0_01_2018
Range Layout
7 Fan Units
DCF 460 - 480kW
8 Fan Units
DCC 530 - 690kW
DCF 490 - 740kW
DCC 470 - 490kW
DCF 470 - 490kW
DCC 520kW
DCF 510kW
DCC 480 - 650kW
DCF 510 - 650kW
DCC 490 - 740kW
DCF 530 - 790kW
DCC 540 - 680kW
DCF 500 - 820kW
DCC 500 - 800kW
DCF 550 - 850kW
9 Fan Units
10 Fan Units
11 Fan Units
12 Fan Units
13 Fan Units
14 Fan Units
(1) DCC Duties based upon 12°C / 7°C
water temperatures 35°C Ambient
(2) Free cool Duties at 15°C / 10°C 3°C Ambient
(3) Condenser fan layout may vary with unit conguration
