Hydraulic Data
DCF Unit Pressure Drop
DCF units are at 20% Ethylene Glycol
Unit pressure drop of the chiller with 20% Ethylene Glycol.
Waterow(l/s)
Unit
4 6 8 10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50
Pressure Drop (kPa)
1 DCF046DR-07DXY0 8.4 15.4 23.8 33.5 44.6 57.1 70.9 86.0 102.5 120.3 139.4 159.9 181.8 204.9 229.4 255.3 282.4 311.0 340.8 372.0 404.5 438.4 473.5 510.1
2 DCF048DR-07DPY0 9.3 17.0 26.3 37.2 49.6 63.5 79.0 96.0 114.6 134.7 156.3 179.4 204.1 230.3 258.1 287.3 318.1 350.4 384.3 419.7 456.6 495.0 535.0 576.5
3 DCF051DR-08DPV0 8.5 15.6 24.1 34.1 45.4 58.1 72.2 87.7 104.6 122.9 142.5 163.6 186.0 209.8 235.0 261.6 289.6 318.9 349.7 381.8 415.3 450.1 486.4 524.1
4 DCF053DR-08DYY0 7.1 13.1 20.3 28.6 38.1 48.6 60.3 73.1 87.1 102.1 118.3 135.6 154.0 173.6 194.2 216.0 238.9 262.9 288.0 314.3 341.6 370.1 399.7 430.4
5 DCF049DR-09DXY0 7.0 13.0 20.1 28.3 37.6 48.0 59.5 72.2 85.9 100.7 116.7 133.7 151.8 171.0 191.4 212.8 235.3 258.9 283.7 309.5 336.4 364.4 393.5 423.7
6 DCF051DR-09DPY0 7.9 14.6 22.6 31.9 42.6 54.5 67.7 82.2 98.0 115.1 133.5 153.2 174.2 196.4 220.0 244.9 271.0 298.4 327.2 357.2 388.5 421.1 455.0 490.1
7 DCF053DR-10DPV0 7.5 13.8 21.4 30.2 40.3 51.6 64.1 77.8 92.8 108.9 126.3 144.9 164.8 185.8 208.1 231.6 256.3 282.3 309.4 337.8 367.4 398.2 430.2 463.5
8 DCF055DR-09DYV0 6.5 12.1 18.8 26.5 35.2 45.0 55.8 67.6 80.4 94.3 109.2 125.2 142.1 160.1 179.1 199.2 220.3 242.4 265.5 289.6 314.8 341.0 368.2 396.4
9 DCF055DR-10DYY0 6.1 11.3 17.6 24.8 33.0 42.1 52.2 63.2 75.2 88.2 102.1 117.0 132.8 149.6 167.3 186.0 205.7 226.3 247.8 270.3 293.8 318.2 343.6 369.9
10 DCF058DR-10DVV0 5.5 9.7 14.6 20.4 26.9 34.2 42.3 51.1 60.8 71.2 82.4 94.3 107.1 120.6 134.9 150.0 165.8 182.5 199.9 218.0 237.0 256.7 277.2 298.5
11 DCF062DR-10FVW0 5.4 9.6 14.7 20.7 27.6 35.3 43.9 53.4 63.7 74.9 87.0 100.0 113.8 128.5 144.1 160.5 177.8 195.9 214.9 234.8 255.6 277.2 299.7 323.0
12 DCF065DR-10FWW0 5.4 9.6 14.7 20.7 27.5 35.3 43.9 53.4 63.7 74.9 87.0 99.9 113.8 128.5 144.0 160.4 177.7 195.9 214.9 234.8 255.5 277.1 299.6 322.9
13 DCF069TR-10GPPY 5.2 9.2 13.9 19.3 25.5 32.4 40.1 48.5 57.6 67.4 78.0 89.4 101.4 114.2 127.7 142.0 157.0 172.7 189.2 206.3 224.2 242.9 262.2 282.3
14 DCF051DR-11DXY0 6.2 11.6 17.9 25.3 33.6 42.9 53.2 64.5 76.7 89.9 104.1 119.3 135.5 152.6 170.7 189.8 209.8 230.9 252.9 275.8 299.8 324.7 350.6 377.5
15 DCF053DR-11DPY0 7.1 13.2 20.5 28.9 38.6 49.4 61.4
74.5 88.8 104.3 121.0 138.8 157.8 178.0 199.4 221.9 245.5 270.4 296.4 323.6 351.9 381.4 412.1 443.9
16 DCF055DR-12DPV0 6.8 12.7 19.7 27.9 37.2 47.6 59.2 71.9 85.7 100.6 116.7 133.9 152.3 171.7 192.3 214.1 236.9 260.9 286.0 312.2 339.6 368.1 397.7 428.4
17 DCF057DR-12DYY0 4.9 8.6 13.0 18.0 23.8 30.2 37.4 45.2 53.7 62.9 72.8 83.4 94.6 106.6 119.2 132.5 146.5 161.2 176.5 192.5 209.3 226.7 244.7 263.5
18 DCF058DR-11DYV0 5.2 9.1 13.7 19.1 25.2 32.0 39.6 47.8 56.9 66.6 77.1 88.2 100.2 112.8 126.2 140.2 155.1 170.6 186.8 203.8 221.5 239.9 259.1 278.9
19 DCF060DR-12DVV0 4.9 8.6 12.9 18.0 23.8 30.2 37.4 45.2 53.7 62.9 72.8 83.3 94.6 106.5 119.1 132.4 146.4 161.1 176.4 192.5 209.2 226.6 244.7 263.4
20 DCF065DR-12FVW0 4.7 8.5 13.0 18.4 24.5 31.3 39.0 47.5 56.7 66.7 77.4 89.0 101.3 114.4 128.3 142.9 158.4 174.6 191.5 209.3 227.8 247.1 267.1 288.0
21 DCF068DR-12FWW0 5.0 8.6 13.0 18.0 23.9 30.5 37.8 45.9 54.7 64.3 74.6 85.7 97.5 110.1 123.4 137.4 152.2 167.8 184.1 201.1 218.8 237.3 256.6 276.6
22 DCF074TR-11GPYY 5.2 8.8 13.1 18.1 23.7 30.1 37.2 44.9 53.3 62.5 72.3 82.8 94.0 105.8 118.4 131.6 145.5 160.1 175.4 191.4 208.1 225.4 243.4 262.2
23 DCF079TR-12GYYY 4.9 8.3 12.3 17.0 22.3 28.3 35.0 42.3 50.2 58.8 68.0 77.9 88.4 99.6 111.4 123.8 136.9 150.7 165.1 180.1 195.8 212.1 229.0 246.6
24 DCF059DR-13DYV0 4.7 8.2 12.4 17.3 22.8 29.0 35.8 43.4 51.5 60.4 69.9 80.0 90.8 102.3 114.4 127.2 140.7 154.8 169.5 184.9 201.0 217.7 235.1 253.1
25 DCF062DR-14DVV0 4.5 7.8 11.9 16.5 21.9 27.8 34.4 41.6 49.5 57.9 67.1 76.8 87.2 98.2 109.9 122.2 135.1 148.6 162.8 177.6 193.1 209.2 225.9 243.2
26 DCF066DR-14FVW0 4.3 7.8 12.0 16.9 22.6 28.9 36.0 43.9 52.4 61.7 71.8 82.5 94.0 106.1 119.1 132.7 147.0 162.1 177.9 194.5 211.7 229.7 248.4 267.8
27 DCF070DR-14FWW0 4.6 7.9 11.9 16.5 21.9 28.0 34.7 42.2 50.3 59.2 68.7 78.9 89.9 101.5 113.8 126.7 140.4 154.8 169.8 185.6 202.0 219.1 236.9 255.5
28 DCF073TR-13GPPY 4.7 7.8 11.5 15.9 20.8 26.3 32.4 39.1 46.3 54.1 62.6 71.6 81.1 91.3 102.0 113.4 125.3 137.8 150.8 164.5 178.7 193.5 208.9 224.8
29 DCF078TR-14GPYY 4.5 7.6 11.2 15.5 20.4 25.9 31.9 38.6 45.8 53.7 62.1 71.1 80.8 91.0 101.8 113.2 125.2 137.7 150.9 164.7 179.0 194.0 209.5 225.6
