1 Output kW refers to the chilled water duty (Based upon 20% Ethylene Glycol).
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
22 DCF074TR-11GPYY
6 757.3 219.8 714.5 240.5 667.6 264.1 617.5 290.1
7 778.8 221.5 734.7 242.2 686.4 265.9 635.0 291.9
8 800.4 223.2 755.1 244.0 705.5 267.7 652.7 293.8
10 844.5 226.8 796.6 247.7 744.4 271.5 688.9 297.6
12 889.5 230.6 839.1 251.6 784.2 275.4 726.1 301.5
14 935.3 234.6 882.4 255.7 825.0 279.5 764.3 305.6
23 DCF079TR-12GYYY
6 805.1 234.1 760.5 256.0 711.5 281.0 659.1 308.6
7 827.9 235.8 782.1 257.8 731.7 282.8 677.7 310.4
8 851.1 237.6 803.9 259.7 752.1 284.7 696.7 312.3
10 898.1 241.3 848.3 263.5 793.7 288.6 735.6 316.2
12 946.1 245.2 893.7 267.5 836.4 292.7 775.5 320.3
14 995.0 249.3 940.0 271.7 880.0 296.9 816.5 324.5
24 DCF059DR-13DYV0
6 573.4 145.9 545.9 161.1 515.1 178.2 481.5 197.4
7 590.5 147.0 562.4 162.1 531.1 179.3 496.7 198.6
8 608.0 148.1 579.2 163.2 546.9 180.3 511.5 199.6
10 643.6 150.3 613.5 165.4 579.2 182.4 542.9 201.9
12 680.2 152.6 648.4 167.7 613.1 184.8 574.9 204.2
14 717.5 155.1 684.6 170.1 647.9 187.3 608.1 206.7
25 DCF062DR-14DVV0
6 593.9 148.6 565.5 164.3 533.8 182.2 498.3 202.1
7 611.8 149.7 582.7 165.3 550.2 183.2 514.5 203.4
8 630.0 150.8 600.2 166.4 566.9 184.3 529.7 204.2
10 667.0 153.0 635.9 168.6 600.0 186.2 562.6 206.6
12 705.0 155.3 672.5 170.9 635.3 188.6 595.8 208.8
14 743.7 157.8 710.1 173.4 671.6 191.1 630.4 211.3
26 DCF066DR-14FVW0
6 644.6 161.6 613.1 178.3 578.0 197.3 540.0 218.9
7 663.8 162.8 631.2 179.4 595.6 198.5 556.3 220.0
8 683.3 164.0 650.0 180.6 613.5 199.8 573.3 221.3
10 723.2 166.6 688.4 183.2 650.2 202.4 608.1 223.9
12 764.1 169.3 727.9 185.9 687.6 205.0 644.0 226.6
14 805.3 172.0 768.4 188.8 726.4 207.8 681.1 229.4
27 DCF070DR-14FWW0
6 678.8 173.5 645.8 191.4 608.8 211.6 569.1 234.6
7 698.7 174.8 664.2 192.5 627.1 213.0 586.4 236.0
8 719.0 176.2 683.7 193.9 645.7 214.3 604.0 237.3
10 760.2 179.0 723.6 196.7 683.8 217.2 640.1 240.2
12 802.5 181.9 764.5 199.6 722.9 220.1 677.3 243.1
14 844.6 184.7 806.3 202.7 763.0 223.2 715.7 246.2
28 DCF073TR-13GPPY
6 718.6 193.5 684.0 213.3 645.2 235.7 601.5 260.1
7 739.9 195.0 704.3 214.8 664.5 237.2 619.1 261.5
8 761.5 196.6 725.0 216.4 684.3 238.8 636.9 262.8
10 805.5 199.9 767.3 219.7 723.9 241.9 673.4 265.6
12
850.6 203.2 810.8 223.1 764.2 245.0 711.0 268.6
14 896.8 206.8 855.3 226.6 805.1 248.1 749.6 271.7
DCF Performance Data EC Fans
