AIREDALE DeltaChill - Technical Data DCC; DCC Performance Data EC Fans

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
142
Chiller Technical Manual 7267818 V1.13.0_01_2018
Air Cooled
Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
98
DCC047DR-08EPV0
5 494.6 138.4 470.0 152.4 442.3 168.5 410.7 185.9
6 508.9 139.4 483.8 153.4 455.3 169.5 422.7 186.9
7 523.5 140.4 497.7 154.5 468.3 170.5 434.9 187.9
8 538.1 141.5 511.7 155.6 481.4 171.5 447.2 188.9
9 552.8 142.6 525.9 156.7 494.7 172.6 459.8 190.0
10 567.6 143.7 540.2 157.8 508.2 173.6 472.5 191.1
99
DCC049DR-08EYY0
5 518.6 150.6 493.0 165.2 463.0 181.5 430.3 199.6
6 533.8 151.8 507.1 166.2 476.2 182.6 442.7 200.7
7 549.2 152.9 521.3 167.3 489.6 183.7 455.3 201.8
8 564.7 154.1 535.7 168.4 503.2 184.8 468.0 203.0
9 579.9 155.2 550.3 169.5 517.0 186.0 481.0 204.1
10 595.2 156.3 564.9 170.7 530.9 187.1 494.1 205.3
100
DCC049DR-10EPV0
5 504.5 132.1 481.2 146.0 454.7 161.8 425.3 179.6
6 519.4 133.1 495.3 146.8 468.6 162.8 438.2 180.5
7 534.5 134.0 510.3 147.9 482.6 163.8 451.4 181.4
8 549.8 135.0 524.8 148.8 496.9 164.7 464.7 182.3
9 565.2 136.0 539.8 149.8 511.3 165.8 478.3 183.2
10 580.6 137.0 554.9 150.8 525.7 166.7 492.0 184.2
101
DCC051DR-10EYY0
5 527.6 143.7 503.5 158.4 476.6 175.2 446.9 193.9
6 542.5 144.6 518.5 159.5 490.9 176.2 460.5 194.9
7 558.2 145.7 533.7 160.5 505.5 177.3 473.9 195.8
8 574.6 146.9 549.1 161.6 520.3 178.4 487.5 196.8
9 590.2 147.8 564.6 162.7 535.3 179.5 501.3 197.7
10 606.3 148.9 580.3 163.8 550.5 180.7 515.4 198.7
102
DCC052DR-09DYV0
5 552.1 153.1 525.3 168.4 494.5 185.8 459.4 204.6
6 568.5 154.3 540.8 169.5 508.9 186.8 472.8 205.7
7 585.1 155.4 556.5 170.7 523.5 187.9 486.5 206.8
8 601.6 156.6 572.3 171.8 538.3 189.0 500.4 207.9
9 618.4 157.8 588.4 173.0 553.3 190.1 514.5 209.0
10 635.2 159.0 604.6 174.3 568.5 191.3 528.8 210.2
1 Output kW refers to the chilled water duty.
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
