1 Output kW refers to the chilled water duty (Based upon 20% Ethylene Glycol).
2 Input kW refers to the unit input power (compressor + fans).
3 Duties applicable for chilled water ∆T between 4 and 8°C.
4 Interpolate for water temperatures between those quoted, do not extrapolate.
5 Water ow rate (l/s) = Output ÷ (Cp x ∆T)
6 For conditions outside of those quoted please refer to Airedale.
Ambient (°C)
Model
Supply
Temp
°C
25°C 30°C 35°C 40°C
Output Input Output Input Output Input Output Input
kW kW kW kW kW kW kW kW
1 DCF046DR-07DXY0
6 474.5 137.6 447.7 150.5 418.3 165.4 386.8 182.0
7 488.0 138.7 460.4 151.6 430.2 166.5 397.9 183.1
8 501.7 139.7 473.3 152.7 442.2 167.6 409.0 184.2
10 529.5 141.9 499.6 155.0 466.8 170.0 431.9 186.6
12 557.9 144.3 526.4 157.4 492.0 172.5 455.5 189.1
14 586.8 146.7 553.7 160.0 517.8 175.1 479.7 191.7
2 DCF048DR-07DPY0
6 491.3 142.0 463.1 155.3 432.4 170.6 399.6 187.5
7 505.1 143.1 476.1 156.5 444.5 171.8 410.9 188.7
8 519.1 144.2 489.3 157.7 456.8 173.0 422.3 189.9
10 547.6 146.6 516.1 160.1 481.9 175.5 445.6 192.3
12 576.6 149.1 543.5 162.7 507.6 178.1 469.6 194.9
14 606.2 151.7 571.5 165.4 533.9 180.8 494.2 197.7
3 DCF051DR-08DPV0
6 513.8 143.6 486.5 157.9 455.8 174.1 421.6 191.7
7 528.7 144.7 500.7 159.1 468.8 175.2 433.7 192.8
8 543.8 145.9 515.1 160.3 482.1 176.3 446.0 194.0
10 574.6 148.4 544.4 162.8 509.1 178.7 471.2 196.3
12 606.0 151.0 573.8 165.3 536.7 181.2 497.1 198.8
14 638.1 153.7 603.7 167.9 564.9 183.8 523.6 201.4
4 DCF053DR-08DYY0
6 534.3 155.9 504.8 170.5 472.4 187.1 437.7 205.5
7 549.5 157.0 519.1 171.7 485.8 188.4 450.1 206.8
8 564.9 158.2 533.6 172.9 499.4 189.6 462.7 208.0
10 596.2 160.7 563.2 175.5 527.1 192.2 488.6 210.6
12 628.2 163.3 593.4 178.1 555.5 194.9 515.2 213.3
14 660.7 166.0 624.3 180.9 584.6 197.7 542.5 216.1
5 DCF049DR-09DXY0
6 485.8 130.4 462.0 143.6 435.7 158.6 406.9 175.4
7 500.3 131.4 475.9 144.6 448.9 159.6 419.1 176.3
8 514.8 132.4 490.1 145.7 462.4 160.7 431.3 177.2
10 545.0 134.6 519.0 147.9 490.0 162.9 456.4 179.1
12 575.9 136.8 548.7 150.1 518.1 165.1 482.2 181.1
14 607.5 139.2 579.3 152.5 546.4 167.3 508.7 183.2
6 DCF051DR-09DPY0
6 504.6 134.5 480.0 148.2 452.5 163.6 421.5 180.3
7 519.6 135.6 494.3 149.3 466.2 164.7 433.9 181.3
8 534.8 136.7 508.9 150.4 479.9 165.8 446.4 182.2
10 565.8 139.0 538.7 152.7 507.9 168.0 472.1 184.2
12 597.7 141.4 569.4 155.1 536.1 170.1 498.5 186.3
14 630.4 143.9 600.8 157.6 564.9 172.2 525.6 188.5
7 DCF053DR-10DPV0
6 526.2 136.8 500.2 150.9 471.6 167.0 439.5 184.8
7 541.9 137.9 515.2 152.0 485.9 168.1 452.7 185.8
8 557.8 139.0 530.8 153.1 500.4 169.2 466.3 186.8
10 589.8 141.2 561.9 155.4 529.8 171.3 493.9 189.0
12
623.6 143.7 594.0 157.8 560.0 173.6 522.5 191.2
14 657.7 146.2 626.9 160.3 590.9 175.9 551.9 193.6
DCF Performance Data EC Fans
