AIREDALE DeltaChill - DCF Mechanical Data - Regular Quiet

Technic al
Chillers
DeltaChill™ Air Cooled and FreeCool
73
Chiller Technical Manual 7267818 V1.13.0_01_2018
FreeCool
1 2 3
DCF046DR-07DXY0 DCF048DR-07DPY0 DCF051DR-08DPV0
FreeCooling Yes Yes Yes
Enhance Capital Allowance No No No
Number of Refrigeration Circuits 2 2 2
Cooling Duty - EC Fans
Nominal Output - Mechanical (1) kW 466.8 481.9 509.1
Nominal Input - Mechanical kW 170.0 175.5 178.7
EER (2) 2.75 2.75 2.85
ESEER 3.80 3.67 3.71
Nominal Output - Free Cooling kW 345.6 348.7 389.9
Ambient temperature for
100% Free Cooling
(5) °C -1.3 -1.6 -0.7
Capacity Steps % 15-35-50-70-85-100 25-45-65-85-100 25-45-65-80-100
Minimum Turndown Ratio 0.16 0.24 0.23
Dimensions (H x W x L) mm 2682 x 2200 x 4846 2682 x 2200 x 4846 2682 x 2200 x 4846
Weight
Machine (3) kg 4465 4345 4450
Operating kg 5060 4940 5065
Water Volume (Total Internal) l 595 595 615
Maximum Waterow l/s 35.1 35.1 35.1
Minimum Waterow l/s 8.0 13.4 13.4
Face Area (Total) m² 2.38 2.38 2.38
Nominal Airow - EC Fans m³/s 41.1 41.1 47.0
Quantity 7 7 8
Maximum Speed - EC Fans rpm 1026 1026 1026
Compressor Trio + Trio Tandem + Trio Tandem + Trio
Quantity of Compressors 6 5 5
Oil Charge Volume (Total) l 3 x 5.3 + 3 x 5.3 2 x 5.3 + 3 x 5.3 2 x 5.3 + 3 x 5.3
Refrigeration R410A / 2088
Charge (Total) kg 24 + 30 24 + 31 24 + 34
GWP Tonnes Equivalent CO
2
tCO2 50 + 63 50 + 65 50 + 71
Refrigerant Control Electronic Expansion Valve (EEV)
Water Inlet / Outlet - Unit DN125 DN125 DN125
Water Drain / Bleed - Evap inch 1/2 1/2 1/2
Water System
Minimum System Water Volume (4) l 1371 2149 2149
Maximum System
Operating Pressure
Bar 10 10 10
DCF Mechanical Data - Regular Quiet
(1) Based on units performance at 15/10°C return/supply temperatures, 35°C ambient, 20% Ethylene Glycol.
All performance data supplied in accordance with BBS EN14511-1:2013
(2) EER = DX Cooling Output / (Compressor input power + Fan Input Power),
(3) Based on standard unit without options, operating weight includes refrigerant charge and water volume.
For unit weights with waterside options tted please refer to Airedale.
(4) For minimum system volume, refer to Design Features & Information - Minimum System Water Volume Calculations
(5) Ambient temperature that full Freecool capacity can be achieved
